W type mosi2 heating element,W mosi2 heater

MoSi2 heating element is a kind of resistance heating element basically made of high pure Molybdenum Disilicide.W shape mosi2 heating elements are superior to the U shape mosi2 heating elements in that the hot zones are longer,requiring fewer elements to heat up the boiler and achieve the required temperature with minimal losses at the cold ends. As a result,W shape molybdenum disilicide heating elements are more cost effective than U shape molybdenum disilicide heating elements. For W type

Hot zone length:Le,mm Cold end length:Lu,mm Shank Spacing:A,mm Diameter:D1/D2 ,mm/mm(Le/Lu)

Specify as: W D1/D2*Le*Lu*3A
